SMP858-TLF Gauge Pressure Transmitter

Hygienic pressure transmitter, designed for food and pharmaceutical industry, is suitable for CIP/SIP cleaning and sterilization. Smart compact design, the wetted parts is made of high quality stainless steel 316L and integral welding, roughness≤0.4um, filling fluid with hygiene standard in line with FDA certification, variety of international standard process connections are available.

Advantage

• Double diaphragm overload protection structure can easily cope with high overload tests.

• Designed for food and pharmaceutical industry, suitable for CIP/SIP cleaning and sterilization.
• Isolated air cavity design to prevent condensation and avoid pollution to the media.
• ASIC and SMT signal transmitting module. Friendly button parameters operation function, display measured data quickly.
• Roughness of stainless steel surface Ra≤ 0. 4μ m, conform to international sterile standard.

• Filling fluid with hygiene standard in line with FDA certification.

Features

• Pressure type: gauge pressure

• Measuring range: 10kPa-3.5MPa
• Output signal: 4-20mA, 4-20mA+HART
• Reference accuracy: ±0.2% URL, ±0.5% URL
• Process connection: Tri-Clamp 1-1/2", Tri-Clamp 2", DIN32676 DN32, ISO2852, DRD ...
• Approvals: 3A, EHEDG, CE, RoHS, Ex-proof certificate

Industry application

• Pharmacy, Food, Milk, Beverage, Juice…
